Farm workers can encounter a variety of respiratory problems ranging from temporary discomfort caused by allergic reactions to fatal asphyxiation. However, the risk of contracting serious lung diseases or death can be significantly decreased by using respiratory protection (Figure 1). See the sidebar for a list of farm work that requires respiratory protection.
|Figure 1. Various respiratory protection devices that can protect you. Respirators in both a) and b) are air purifying devices and can protect you from hazardous vapors. Dust masks shown in c) and d) will protect the lungs from small particles but are not effective for hazardous vapors. All protection devices need proper fit.|
|Who Needs Respiratory Protection?|
Use this list to help you or a safety equipment specialist select the right protection equipment for the job.
Respiratory protection equipment is placed in one of two categories: 1) air purifying devices; or, 2) oxygen providing respirators.
Air purifying devices
Air purifying devices remove contaminants from the air and are used only where there is a sufficient oxygen supply. These devices include mechanical filter, chemical cartridge (Figures 1 - a and b), and canister gas mask respirators.
Mechanical filter respiratory protection devices are commonly known as dust masks (Figures 1 - c and d). These simple filters consist of a molded filter designed to cover the nose and mouth. The filter is held in place by one or two elastic straps that are stretched over the head. Masks with two elastic straps, in general, fit better. Some dust masks have a valve built into the filtering substance to allow easier breathing. Dust masks should be discarded when the filter becomes clogged.
Dust masks provide protection against airborne dust particles (chemical, mineral, field, or barn), chaff, pollen, and non-toxic paint spray dusts. However, sufficient levels of oxygen must be present in the air to be filtered.
Chemical cartridge respirators
Chemical cartridge respirators provide a higher level of protection than dust masks. These respirators consist of a soft, silicone face piece, which covers the nose and mouth and contains a valve to control air movement through the respirator. Replaceable cartridges containing activated carbon are used to filter incoming air. Pre-filters are usually installed on the outside of the cartridges. Respirators are held snugly against the user's face using elastic straps or a harness. A half respirator covers only the nose and mouth of the user; a full-face respirator includes an eye shield and covers the entire face and eyes.
As a respirator user, you must anticipate the type of hazard to choose the correct cartridge to provide maximum protection. Most cartridges are designed to provide protection for a specific type of chemical hazard such as pesticides, ammonia, anhydrous ammonia, etc.
Gas masks use large capacity cartridges (canisters), which allow for longer working times in high levels of contaminants compared to typical respirators. These masks provide full face coverage. Cartridges may be mounted on the face piece or at the end of a flexible hose to allow mounting at the user's belt. Gas masks provide protection against pesticides and often toxic airborne materials. Like mechanical filters and chemical cartridge respirators, gas masks require sufficient levels of oxygen in the air to be filtered.
Oxygen-providing respirators are used in oxygen-defi-cient atmospheres. These respirators include suppliedair respirators and self-contained breathing apparatus (SCBA).
Supplied-air respiratory protection
Supplied-air respirators provide users with fresh air from a remote source such as a portable air compressor or from pressurized tanks. The fresh-air source can be located up to 300 feet from the user. Air compressors must be located in a clean-air area. Supplied-air respirators have face pieces similar to those used by chemical cartridge respirators or gas masks.
Self-contained breathing apparatus (SCBA)
A SCBA requires that you carry an oxygen supply, contained in a compressed air tank, on your back. These respirators can be used in silos, manure pits, and grain storage areas and during the fumigation of structures.
Table 1 identifies some hazardous air condition sources common to agriculture and their potential contaminants. If you are working with or in these sources, protective equipment should be used (see Table 1).
If you are unsure which type of protective equipment is best for your work, ask the professionals who sell safety equipment or check the Materials Safety Data Sheets (MSDS) for recommendations.
|Table 1. Hazardous air sources and contaminants|
feathers and feather particles
dried skin material
dried fecal material
dried feed products
hair and skin particles
dried feed products
dried fecal particles
Most types of protective respiratory equipment can be found at safety supply stores. Farm supply stores and agricultural chemical suppliers are also good sources. If these suppliers do not have the equipment you need, they can order the equipment for you. Make sure to test-fit respiratory devices to ensure a proper seal between your face and the face piece.
In Case of Emergency
If someone else is overcome by toxic gases:
Act Quickly, but Thoughtfully!
A few minutes without oxygen can cause brain damage or death for the victim, but if you act without thinking about your own safety, you could also become a victim.
Call for Help
Make sure everyone in the work area and at least one person outside the work area is aware of the hazards that may be present. Each of these people needs to know how to contact emergency rescue personnel and be able to convey any information rescue teams may need (i.e. physical address, directions to the location, hazardous materials present etc.):
Respiratory equipment can safeguard your health and save your life in any hazardous air condition. However, when using such equipment without proper care and precautions, the device may be ineffective. A list of guidelines and precautions that every worker should comply to when using protective respiratory equipment follows:
A change in smell or taste or the initiation of coughing while using filter cartridges may indicate that hazardous materials are coming through the filter and it should be changed. Consider setting a regular schedule to change the filter if the contaminant cannot be noticed by the five senses.
If you use a pre-filter for more than five or six hours a day, change the filter daily. Changing filter cartridges before breathing becomes difficult is extremely important.
Proper maintenance is a key for proper protection - follow these tips:
Caution: Often, it is necessary to use other protective equipment and clothing when using respiratory protective equipment, such as special gloves, eye protection, and long sleeve shirts.
Grisso, R.D., S. Gay, G. Hetzel, and B. Stone. 2004. Farmer's Lung: Causes and Symptoms of Mold and Dust Induced Respiratory Illness. Virginia Cooperative Extension publication 442-602, Virginia Tech, Blacksburg, Va.
Murphy, D.J., and C.M. LaCross. Farm Respiratory Protection. The Pennsylvania State University, Publication E-36, University Park, Pa. www.age.psu.edu/extension/factsheets/e/E36.pdf
Murphy, D.J. Farm Respiratory Hazards. ThePennsylvania State University, Publication Safety-26, University Park, Pa. www.age.psu.edu/extension/factsheets/e/E26.pdf
The authors would like to express their appreciation for the review and comments made by Extension agents Glenn Chappell, Prince George County; Keith Dickinson, Fauquier County; Samuel M. Johnson, Westmoreland County; and Tom Stanley, Augusta County; Superintendent Robert Pitman, Eastern Virginia Agricultural Research and Extension Center; Associate Professor and Extension Soybean Specialist David Holshouser, Tidewater Agricultural Research and Extension Center; and Instructor Stanley Mariger, Department of Biological Systems Engineering, and Associate Professor Ray Smith, Department of Crop and Soil Environmental Sciences, Virginia Tech.
Reviewed by Bobby Grisso, Extension Specialist, Biological Systems Engineering
Virginia Cooperative Extension materials are available for public use, re-print, or citation without further permission, provided the use includes credit to the author and to Virginia Cooperative Extension, Virginia Tech, and Virginia State University.
Issued in furtherance of Cooperative Extension work, Virginia Polytechnic Institute and State University, Virginia State University, and the U.S. Department of Agriculture cooperating. Alan L. Grant, Dean, College of Agriculture and Life Sciences; Edwin J. Jones, Director, Virginia Cooperative Extension, Virginia Tech, Blacksburg; Jewel E. Hairston, Administrator, 1890 Extension Program, Virginia State, Petersburg.
May 1, 2009
